Participants will learn why robust cable joints and terminations are critical for dependable electrical connection, mechanical support and network integrity. Emphasis will be on MV-rated XLPE and paper-insulated lead-covered (PILC) cables, covering their theory, construction, preparation, jointing and termination . You’ll engage with manufacturer-specific specifications, stress-control principles and quality assurance protocols to ensure every joint and termination meets performance and safety standards .

Target Market

This course is tailored for:

• Cable Jointers, Electricians and Technicians responsible for MV cable installations
• Electrical Engineers and Supervisors seeking deeper understanding of cable accessory applications
• Maintenance Managers and Asset Reliability Professionals aiming to minimise network downtime
• Contractors and Consultants involved in designing or specifying cable joints and terminations

Course Objectives

By the end of the course, delegates will be able to:

1. Explain MV cable construction and insulation principles for both XLPE and PILC types
2. Interpret and apply manufacturer’s specifications and industry standards to cable jointing and terminating
3. Prepare and strip cables correctly, including semiconductor removal and conductor shaping
4. Install stress-control, sealing and insulation materials using heat-shrink and cold-shrink techniques
5. Execute straight, branch and transition joints on single-core and three-core cables with precision
6. Perform terminations into switchgear and outdoor fittings using mechanical connectors and sealing tubes
7. Use specialized tools (e.g., spiking guns, crimpers, cable strippers) and employ “tricks of the trade” for efficient workflows
8. Conduct MV insulation resistance and continuity tests, plus post-jointing inspections to verify joint integrity

Day 1 – Theory and Fundamentals

• Introduction to MV Power Cables: overview of cable types, applications and network roles
• XLPE vs. PILC Construction: material properties, moisture ingress issues and ageing mechanisms
• Industry Standards & Specifications: IEC 60502, IEEE Std Std 48 and manufacturers’ datasheets
• Safety & Documentation: OHS regulations, risk assessment and work permits
• Cable Identification & Testing Principles: core identification, spiking theory and pre-installation checks
• Stress Control & Insulation Breakdown: theory behind tracking, erosion and stress relief
• Review of Industry Manuals: guided look at UK Power Networks LV Jointing Manual procedures for best practices

Day 2 – Practical Application & Theoretical Assessment

• Theoretical Assessment: short written test covering Day 1 content
• Cable Preparation Workshop: hands-on stripping of XLPE and PILC cables, semiconductor removal and conductor shaping
• Material Application: applying bonding media, mastic, stress-control tubes and pre-moulded components
• XLPE Jointing Techniques: heat-shrink and cold-shrink methods for single-core and triplex cables
• PILC Jointing Techniques: lead extrusion, poured insulation and resin filling methods
• Specialized Tools Demo: spiking guns, crimpers, hydraulic presses and thickness gauges

Day 3 – Advanced Practical & Certification Assessment

• Termination Practices: mechanical connector installation into switchgear and outdoor interfaces
• Live Jointing Simulation: end-to-end jointing sequence under timed conditions
• MV Testing & Verification: insulation resistance, continuity and partial discharge checks
• Troubleshooting & Quality Control: identifying joint failures, moisture paths and repair strategies
• Practical Assessment: delegates complete a full joint and termination to Peganix quality criteria
• Course Review & Feedback: group debrief, lessons learned and Q&A
